Description
Specifications
- Ship Weight : 146.26 LBS.
- Capacity (L) : 6
- Capacity (gal) : 6
- Depth (in) : 24
- Design : Electric
- Drain Included : No
- Energy Use : 36 kW
- Heat Source : Electric
- Height (in) : 12
- Hertz (Hz) : 60
- High or Low Temp : High
- Inside Height (in) : 12
- Insulation Thickness : Fiberglass insulation
- Length (in) : 24
- Material : Stainless Steel
- Maximum Water Temperature (°F) : 180
- Phase : Three Phase
- Power : 208V/60Hz/36kW/3-ph
- Series : Compact Booster Heater
- Size : 12 in (H) x 18 in (W) x 24 in (Depth)
- Tank Capacity (gal) : 6
- Temperature Control : Hi-limit
- Voltage (V AC) : 208
- Voltage (V) : 208
- Volts (Single Phase) : 208
- Wash Tank Capacity (L) : 22.7
- Water Capacity (L) : 6
- Water Capacity (gal) : 6
- Wattage (W) : 36000
- Wattage (kW) : 36
- Width (in) : 18
DescriptionThe Hatco – C-36-208-3 – 208V 36 kW Compact Booster Heater has a tank capacity of six gallons and can increase the temperature of up to 361 gallons of water by 40 degrees an hour to 206 gallons of water by 70 degrees. It has both low-water and high-temperature cutoff systems in place to preserve the heating system and reduce wear and tear on the machine. Other features of the Hatco 208V 36 kW Compact Booster Heater (C-36-208-3) include fiberglass insulation, stainless steel construction, swing away panels for maintenance access, and relief valves for both temperature and pressure. The C-36-208-3 is UL and CSA listed as well as NSF certified.
