Description
Part Number: 284-000060
UPC: 888226213165
Featuring a high performance design, at a general purpose price, the new 4 Flute APG series will increase speeds and feeds without increasing your costs. Premium solid carbide.
Specifications
| Brand | Monster |
|---|---|
| Diameter | 1/8″ |
| Diameter (Metric) | 3.18mm |
| Length of Cut (Decimal Inch) | 0.500 in. |
| Shank (Decimal Inch) | 0.1250 in. |
| Overall Length (Decimal Inch) | 1.5000 in. |
| Tool Length | Regular |
| End Style | Square |
| Flute Type | Spiral |
| Material Grade | C-2 Sub-Micron |
| Center Cutting | Yes |
| Spiral Direction | Right Hand |
| Shank Tolerance | +0.0000 / -0.0004 |
| Flutes | 4 |
| Diameter (Decimal Inch) | 0.1250 in. |
| Length of Cut | 1/2″ |
| Shank Diameter | 1/8″ |
| Overall Length | 1-1/2″ |
| Single/Double End | Single End |
| Finish | Bright |
| Helix | Variable |
| Material | Solid Tungsten Carbide |
| Index | Unequal |
| Cut Direction | Right Hand |
| Diameter Tolerance | +0.000 / -0.002 |
| NOTE | Included in the following set: 284-888881 |
