Description
- Range: 1.000″
- Face diameter: 2-1/4″
- Graduations: 0.001″
- Shockless, hardened steel gear train and jewel bearings
- Lug on center of the back
Starrett catalog number 25-441J.
These indicators have a shockless, hardened steel gear train and jewel bearings. They are furnished with a lug on the center of the back.
This is an AGD Group 2 indicator with a 2.25″ Diameter face, 0.375″ shank, and #4-48 tip thread.
| Range | 0″ – 1″ (0 mm – 25 mm) |
| Resolution | 0.001″ (0.03 mm) |
| A.G.D. Group | 2 |
| Face Diameter | 2.25″ (57.1 mm) |
| Shank Size | 0.375″ (9.52 mm) |
| Thread Tip | #4-48 |
| Dial Reading | 0-100-0 |
| Revolution | 0.100″ (2.54 mm) |
| Type | Lug backing |
| Dial Face | Continuous Dial |
