Description
V-Groove – Folding – Signmaking CNC Router Cutter
663.1
Specifications
| Item Code | 663.101.11 |
|---|---|
| D | 2-1/16″ |
| l | 25mm |
| L | 4″ |
| A | 91° |
| S | 20mm |
| Z | 1 |
| MAT | HW |
| RH-LH | RH |
| 790.360.01 | |
| 991.061.00 | |
| 990.020.00 | |
| 990.073.00 | |
| 990.036.00 |
TECHNICAL DETAILS:
- Super-strength steel.
- 1 cutting edge (Z1).
- 2 cutting edges (Z2).
- 790.360.01 – Optional S790.360.03: 36x12x1,5mm HW-SMG replaceable knife (4 cutting edges 35°).
APPLICATION:
This innovative CNC router bit offers you an endless range of possibilities for V-Groove, miter folds, signmaking, lettering and chamfer edges.
The tool mounts a high grade HWM reversible knife ideal for general purpose, chipboard and plywood, but a higher quality is available for laminated and MDF material.
Safety Tips:
The TW-006 Torque Screwdriver is recommended
for the proper fastening of screws.
